Project Submission I designed and built the furniture for this small apartment
This was a fun challenge because the entire apartment is only about 55m² (590 sq feet) with two bedrooms, so most commercially available furniture was simply too large for the space. The clients wanted to make the most out of every square meter, so I designed the entire interior around smaller pieces that would still be comfortable and functional.
I'm an architect, so I designed the whole space in Rhino first and then fabricated almost everything you see in my shop. Beyond the furniture, I also built the TV console, the sculptural wall cladding that continues into the entry hallway, the suspended light fixture, the mirror and picture frames, and the sofa and chair frames.
Most of the woodwork is solid maple, stained to a walnut color and finished with water-based polyurethane.
The TV and hallway wall was probably the most involved part. The fluted sections started as 1" thick glued-up maple panels and were CNC machined, leaving about 1/2" of solid material behind. I designed the fluting in Rhino so it starts and stops exactly where the angular pieces need to attach, leaving flat mounting areas.
The 3/4" maple angular pieces sit on 1" spacers so they float in front of the fluted surface. They're glued and screwed from behind with no visible fasteners. The wall sections sit on roughly 1 1/2" frames and hang on French cleats, which also created enough space behind them to hide LED strips for indirect lighting.
The floating TV console is also all maple. The black sections are maple drawer fronts painted for contrast. What looks like a separate shelf on the right is actually part of the same assembly, with the angular back providing the support.
I also built the dining table and chair frames. The table base is made from individually CNC-cut maple slats fitted into circular maple rings, with a Calacatta stone top. The chairs and sofa use floating mortise-and-tenon joinery with Domino tenons. I built the frames in my shop and then sent them out for upholstery.
The two small stools were made from glued-up stacks of maple and turned on a CNC lathe.
The black angular element running across the ceiling is actually a light fixture I designed and built from plywood. It's a hollow structure with all of the wiring concealed inside, and the shape and openings for the individual lights were CNC cut before the entire assembly was painted black.
I also made the floating maple frames for the mirrors and artwork. I worked with a local artist who created the artwork itself.
The whole project took about two weeks to design and another month and a half to fabricate and install. Everything was fabricated in my shop and then brought to the apartment for installation.
It was a lot to fit into a small space, but designing everything together meant I could control the proportions of every piece and make the most of the available room while keeping the same material and design language throughout.
Happy to answer any questions about the design or build process.
